Chiyu SEMAC-S1 Access Control Panel OSDP :

The Chiyu SEMAC-S1 Access Control Panel with OSDP support is a professional-grade controller designed for secure and scalable access management systems. Built to meet modern security requirements, this panel enables reliable communication between readers and the central control system using OSDP protocol, ensuring encrypted data transmission and improved system security.

Ideal for commercial buildings, offices, industrial facilities, and high-security sites, the SEMAC-S1 provides stable performance and seamless integration with RFID readers, biometric devices, and door locking mechanisms. Its intelligent architecture supports efficient user management, real-time monitoring, and flexible access configuration.

Engineered for durability and consistent operation, the panel performs reliably in demanding environments. It simplifies installation and system expansion, making it suitable for both new deployments and upgrades. With advanced communication security and dependable hardware design, the SEMAC-S1 delivers a robust foundation for professional access control infrastructure.

Technical Specifications

Verification Mode: Card / Password
Software Application: SoMac
Card Capacity: 20,000 (50,000extendable)
Access Control: S1: OSDP door dual directions
Communications: TCP/IP, Wiegand/RS485
DIO Support: DI: 5 / DO: 4
Inbuilt Relays (Max. Power Loading):

(1) Door Lock / Event Handle
(2) NO. (5A 250VAC / 30VDC / 10A 125VAC)
(3) NC. (3A 250VAC / 5A 30VDC)

System Log: 1,536 entries
Entry Log: 65,535 entries
Time Set / Time Zone / Group: 255 / 120 / 255 sets
Holiday: Yes
Remote Control / Event Handle: Yes / Yes
Multiple Badge / Fast Registry: 10 Groups / Yes
Anti-Pass Back / Anti Duress: Yes / Yes
Power Consumption: 440mA ± 5%
Power Requirement: 9 ~ 24VDC / 1A
Operation Temperature: 0°C ~ 65°C
Operation Humidity: 5% ~ 80% RH
Panel Dimension / Weight: 143 x 114 x 21mm / 160g
Power Box (3A): 205 x 265 x 76 / 2.2Kg (Option)
Power Box (3.5A / UPS): 205 x 265 x 76 / 2.2Kg (Option)
Accessories: WG/OSDP reader
