Biometrics Fingerprint USB Scanner Five-O Mobile 4-4-2 Scanner

Five-O Mobile 10 print USB Fingerprint Scanner offered by Integrated Biometrics is the first FBI-certified fingerprint FAP 50 enrollment and verification package small enough to fit in a shirt pocket. Built for law enforcement, military, border control, and national ID programs, FIVE-0 can operate for hours using mobile phone power.

Description

Five-O is a Mobile Fingerprint USB Scanner offered by Integrated Biometrics is the first FBI-certified fingerprint FAP 50 enrollment and verification package small enough to fit in a shirt pocket. IntelliTech Biometrics has been the sole distributor in Pakistan for Integrated Biometrics since 2014, and since then has been providing service, support, and warranty all over Pakistan, existing in Karachi, Lahore & Islamabad.

The Biometrics Five-O Mobile 4-4-2 Fingerprint USB Scanner is one of the best biometric 10-print fingerprint scanners available. The scanner’s portability, combined with its ability to handle 10-print registration and verification, makes the Five-O Mobile 4-4-2 Scanner the top choice in the market. It is suitable for large deployments, including applications such as the National Authority Database (National ID), Border Security, Airport Security, Elections, and Criminal Identification.

The portability of this scanner with a 10-print Registration and verification makes the Five-O Mobile 4-4-2 Scanner the best device on the market.

Faster

  • Rapid dry finger capture? No need to clean latent prints in high-volume situations
  • Easy integration via single SDK for all Integrated Biometrics FBI-certified products

Better

  • Unaffected by extreme temperatures, direct sunlight, or bright artificial lights Compact, lightweight, and rugged
  • Rejects common spoofing attacks
  • Emits no bright lights during scans
  • Meets or exceeds US military durability specifications

Smarter

  • Competitive pricingExtremely low power consumption
  • Eliminates consumables (silicone membranes or cleaning tape)
  • Lower maintenance costs
Specifications
  • OS Support & System Requirements
  • OS SupportWindows Desktop Editions 7, 8, 10, 11
    Linux Kernel 4.0 or newer (32/64 bit, ARMv6, ARMv7)
  • Ubuntu 18.04, 20.04 or newer Debian 10, 11, or newer
    Android 10, 11, 12
  • CPU x86 and x64 | 2.0GHz or higher ARM | 1.0 GHz or higher
  • Memory 512MB or higher
  • Windows Linux Android Images & Capture
    Sensor Type
    LES
  • Camera ]TFT
  • Resolution 500 ppi
  • Grayscale 256 grayscale dynamic range
  • Image Size 1600 x 1000 pixels
  • Supported Image Formats RAW, JPEG2000, BMP, PNG, WSQ (FBI-approved)
  • Encryption N/A
  • FBI / Image Certifications FBI Appendix F-certified, Mobile ID IQS FAP 50, GSA FIPS201
  • Speed Min frame rate slaps > 7.7FPS Min frame rate rolls > 10FPS
  • API Interface Capture single-finger/four-finger direct, single-finger rolls, multidevice / multi-thread support
  • Quality Scoring NFIQ v1 supported on all OSes and NFIQ2 for Windows
  • Platen Size 85.85 mm x 53.97 mm / 3.38” x 2.12”
  • Sensing Area 81.28 mm x 50.80 mm / 3.20” x 2.00”
  • Scanner Assembly Dimensions 113.4 mm x 82.9 mm x 17.2 mm / 4.46” x 3.26” x 0.68” | Desktop
    4mm x 79.9mm x 16.2mm / 4.35″ x 3.15″ x 0.64″ | Embedded
  • Five 0 Size Power & Connectors Interface
    USB 2.0
  • Power Source USB Host
  • USB Voltage Level 4.4V to 5.25V
  • Conformance & Certifications USB Certification
    USB-IF USB.ORG
  • FCC/CE Comformance FCC Part15 (per ANSI C62.4:2003) Class A, CSA ICES-003 Class A, CE Emissions: EN55022:2006 Class A, CE Immunity EN 55024:1998/A1:2001/A2:2003, IEC61000-4-2
  • Air Discharge / Contact Discharge In compliance with IEC 61000-4-2
  • Equipment Safety IEC 60950-1
  • Hazardous Material RoHS Directive 2002/95/EC
    RoHS Directive 2011/65/EU with amendment 2015/863
  • Vibration Test IEC 60068-2-64
  • Compliance/Certifications Fingerprint Template Output Formats
    ISO_19794_2_2005/2011, ISO_19794_4_2005/2011
    ANSI_INCITS_378_2004/ANSI_INCITS_381_2004
    500 PPI fingerprint capture supporting rolls and flats
    ISO 9001:2015
    iBeta ISO 30107-3 Compliant
    MOSIP L1 Compliant
    iBeta Compliance
    MOSIP Compliance
    Temperature & Humidity
    Operating Temperature
    -10°C ~ +55°C / 14°F ~ 131°F
  • Humidity
    30~85% RH < 40°C / 104°F (Non-condensing) Storage Temperature -40°C ~ +80°C / -40°F ~ 176°F Surface & Systems Ingress Protection / Water / Dust IP65 Sealed bezel to scanning surface Surface Durability MIL-C-675c 4.5010, MIL-STD-810F Cleaning & Sanitization For proper cleaning and disinfection of IB products, visit /cleaning Mean-Time Between Failures (MTBF) Based on 200 full 10-print flats enrollments per day, the Five-0 MTBF is 22.2 years.
